Snap Action Switch - SPDT, Roller Plunger, 20A, Screw Terminal, BA Series MPN:BA-2RQ1-A2
The Honeywell BA Series Snap Action Switch is a reliable and versatile limit switch designed for a wide range of applications. With its overtravel roller plunger actuator and spring return mechanism, it provides smooth and consistent operation, making it ideal for use in industrial automation, robotics, and machinery control. The switch's SPDT contact form and 20A rating support both normally open and normally closed operations, while its compact size and screw terminal connections make it easy to integrate into existing systems. Its durable construction and wide temperature range ensure reliable performance in harsh environments.
Top product features:
- The switch features a single-pole double-throw (SPDT) contact form, supporting both normally open and normally closed operations.
- The switch has an overtravel roller plunger actuator with a length of 1.94 inches.
- The switch has a spring return mechanism for reliable operation.
Top product applications:
- Machine Guarding
- Industrial Automation and Control Systems
- Material Handling Systems
The Honeywell Snap Action Switch is a basic limit switch from the BA Series, equipped with an overtravel roller plunger actuator and spring return mechanism. It features a single-pole double-throw (SPDT) contact form, supporting both normally open and normally closed operations. The switch body is constructed from phenolic material and has bottom-facing screw terminals with bottom-facing screw terminals for secure electrical connections.
Key Features:
- - Actuator Type: Overtravel roller plunger with 1.94" length
- - Contact Rating: 20A at 125–480V AC
- 0.5A at 125V DC
- 0.25A at 250V DC
- - Electrical Connection: Bottom-facing screw terminal (6-32 x 0.218 in.)
- - Mounting Dimensions: Center mounting hole distance of 1"
- - Operating Force: Minimum of 14 ozf, maximum of 22 ozf
- release force of 10 ozf
- - Differential Travel: Minimum of 0.002 in., maximum of 0.0075 in.
- - Pretravel/Overtravel: Maximum pretravel of 0.05 in.
- overtravel up to 0.219 in.
- - Temperature Range: Operates between -67°F to +185°F (-55°C to +85°C)
- - Body Size: Width—1.94", Height—0.95", Depth—0.07"
- - Standards Compliance: CE, CSA, ENEC, UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.50
- Package Width: 2.00
- Package Height: 0.80
- Package Weight: 0.10
