Y-Check Valve, 2-1/2", PVC/FPM, Flanged MPN:YC10250F

• HAYWARD FLOW CONTROL YC10250F is a 2-1/2 in Y-check valve with a PVC body, PVC piston check mechanism, and flanged ends. It is intended for general-purpose water service and is configured for one-direction flow with a piston check mechanism. The Y-style body includes a service-access configuration, and the valve can be mounted in horizontal or vertical positions.

  Key Features:

  • Valve type: Y-check valve with single-flow design and piston check mechanism.
  • Size and connections: 2-1/2 in nominal valve size with flange x flange connections
  • ANSI Flange Class 150.
  • Materials: PVC body and check mechanism with FPM/FKM seal and seat materials.
  • Pressure and temperature: Maximum water pressure 150 psi at 70 Degrees F
  • operating temperature range 34 Degrees F to 140 Degrees F.
  • Flow specifications: Cv 75, rated flow 75 gpm, and full-flow configuration.
  • Cracking pressure: 1.0 psi.
  • Mounting orientation: Horizontal or vertical.
  • Dimensions: Overall length 16.77 in, overall height 9 19/32 in, width 4 11/16 in.
  • Standard: ASTM D1784.
