Ball Check Valve, TC Series, Inline, 1 1/4 in, Flange x Flange, CPVC Body MPN:TC20125FE

The HAYWARD FLOW CONTROL TC20125FE is an inline ball check valve with a CPVC body and 1-1/4 in flanged connections on both sides. It uses a ball check mechanism and is configured for one-direction flow and reverse-flow checking. This 2-way valve is for media: corrosive chemicals compatible with CPVC and EPDM materials. Mounting orientation: horizontal or vertical.

Key Features:

• - Valve type: Ball check valve with inline body style
• - Body material: CPVC
• - Check mechanism: Ball
• - Connection size: 1-1/4 in on side 1 and side 2
• - Connection type: Flange on both sides
• - Cracking pressure: 1.5 psi
• - Flow coefficient (Cv): 25
• - Maximum operating pressure: 235 psi
• - Operating temperature range: 34 Degrees F to 70 Degrees F
• - Seal material: EPDM
• - Seat material: EPDM
• - Media compatibility: Corrosive chemicals compatible with CPVC and EPDM materials
• - Mounting orientation: Horizontal or vertical
• - Certification: NSF 61
• - Standards: ANSI 372, ANSI 61, ASTM D1784, ASTM D4101
