Ball Check Valve, TC Series, 2 1/2 in, Flange x Flange, Inline, CPVC MPN:TC2250F

• The HAYWARD FLOW CONTROL TC2250F is an inline ball check valve for one-way flow control in liquid handling and process piping systems. It uses a ball check mechanism for one-way flow control. This 2-way valve features a CPVC body with 2 1/2 in flange connections on both ends, a 1.5 psi cracking pressure, and mounting options for horizontal or vertical installation.

  Key Features:

  • Valve type: Ball check valve with inline body style.
  • Body material: CPVC.
  • Check mechanism: Ball.
  • Connection size: 2 1/2 in on side 1 and side 2.
  • Connection type: Flange on both ends.
  • Flow capacity: Cv 170.
  • Cracking pressure: 1.5 psi.
  • Maximum operating pressure: 150 psi.
  • Operating temperature range: 34 degrees F to 140 degrees F.
  • Seal material: FKM
  • seat material: EPDM.
  • Listed media compatibility: Corrosive chemicals.
  • Mounting orientation: Horizontal, vertical.
  • Certification: NSF 61.
  • Standards: ANSI 372, ANSI 61, ASTM D1784, ASTM D4101.
