Ball Check Valve, TC Series, 2 1/2 in, Inline, Flange x Flange, PVC Body MPN:TC1250F
Free Shipping
In Stock
The Hayward Check Valve is a reliable and efficient solution for various applications, including pool and spa equipment, water treatment systems, and industrial processes. Its durable design ensures smooth water flow while preventing backflow and pressure surges, reducing wear and tear on equipment and extending its lifespan. With a compact size and lightweight construction, this check valve is easy to install and maintain, making it an ideal choice for a wide range of industries and settings, from residential pools to commercial water treatment facilities.
Top product features:
- Check Valve:
- Allows one-way flow of water, preventing back-siphoning or reverse flow
- Prevents water from flowing backwards, ensuring proper system operation
Top product applications:
- Pool Plumbing
- Well Pump System
- Water Treatment System
HAYWARD FLOW CONTROL TC1250F is an inline 2-way ball check valve with a PVC body and 2 1/2 in flanged connections on both ends. It uses a ball check mechanism configured for one-way flow and reverse-flow checking for use in liquid handling and process lines with compatible corrosive chemicals. Mounting orientation: horizontal or vertical. The valve has a 1.5 psi cracking pressure.
Key Features:
- Ball check mechanism: Uses a free-moving ball to control one-way flow and help check reverse flow.
- Body material: PVC.
- Connection size: 2 1/2 in on side 1 and side 2.
- Connection type: Flange on both ends.
- Flow capacity: Cv 170.
- Pressure rating: Maximum operating pressure 150 psi.
- Temperature range: 34 Degrees F to 140 Degrees F.
- Seal material: FKM
- seat material: EPDM.
- Media compatibility: For compatible corrosive chemicals.
- Certifications/standards: Meets multiple NSF, ANSI, and ASTM standards.
- Valve style: Inline, 2-way
- valve series: TC.
- Overall height: 11 1/4 in.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.00
- Package Width: 9.50
- Package Height: 9.50
- Package Weight: 13.00
