Ball Check Valve, TC Series, Inline, PVC Body, 2 1/2 in Flanged, EPDM Seal MPN:TC1250FE
Free Shipping
In Stock
The Hayward Check Valve is a reliable solution for plumbing and irrigation systems. Designed to prevent backflow and ensure water flows in one direction, this check valve is perfect for pools, water features, and other applications where water pressure and flow control are crucial. Its durable construction and efficient design make it an ideal choice for both residential and commercial use. By installing a Hayward Check Valve, you can prevent water damage, reduce maintenance costs, and ensure a safe and reliable water supply. Suitable for a variety of applications, including pool systems, water treatment plants, and industrial processes.
Top product features:
- It allows fluid to flow in one direction while preventing backflow.
- It is designed to be installed in a piping system.
- It is a mechanical device that requires no electricity to operate.
Top product applications:
- Pools and hot tubs
- Water circulation systems
- Well water circulation systems
HAYWARD FLOW CONTROL TC1250FE is an inline ball check valve intended to permit flow in one direction and restrict reverse flow in liquid handling systems. This 2-way valve uses a ball check mechanism and is constructed with a PVC body, EPDM seal, and EPDM seat. It is for use with compatible corrosive chemical applications and can be mounted in horizontal or vertical orientations.
Key Features:
- Ball check mechanism operates based on flow direction and is intended to reduce backflow.
- 2 1/2 in nominal valve size with 2 1/2 in flange connections on both sides.
- PVC body construction for chemical handling applications.
- Cv: 170.
- Cracking Pressure: 1.5 psi.
- Maximum Operating Pressure: 150 psi.
- Operating Temperature Range: 34 degrees F to 140 degrees F.
- Mounting Orientation: Horizontal, Vertical.
- NSF Certification: NSF 61.
- Standards: ANSI 372, ANSI 61, ASTM D1784, ASTM D4101.
- Overall Height: 11 1/4 in.
- Valve Series: TC.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 10.00
- Package Width: 10.00
- Package Height: 20.00
- Package Weight: 13.00
