Ball Check Valve, TC Series, Inline, 1 in Socket x 1 in Socket, Polypropylene MPN:TC30100S
Free Shipping
In Stock
The Hayward Check Valve is a reliable and efficient solution for various applications, including pool and spa systems. Its US origin ensures high-quality construction, while its compact design allows for easy installation in tight spaces. This valve prevents backflow and ensures a smooth flow of water, reducing the risk of damage and maintenance issues. Suitable for residential and commercial use, it's an ideal choice for pool owners, builders, and contractors looking for a reliable and easy-to-install check valve. Its compact size and lightweight design make it easy to handle and transport.
Top product features:
- It allows fluid to flow in one direction while preventing backflow.
- It is designed to withstand standard pool water conditions.
- It is a pre-assembled unit.
Top product applications:
- Pool Equipment
- Well Pump
- Filtration Systems
The HAYWARD FLOW CONTROL TC30100S is an inline 2-way ball check valve with a polypropylene body for one-way flow applications and reverse-flow restriction in liquid handling systems. It uses a ball check mechanism and is intended for corrosive chemicals, with 1 in. socket connections on both sides for inline installation. The valve can be mounted in horizontal or vertical orientations and has a 1.5 psi cracking pressure.
Key Features:
- Ball check mechanism: Uses a free-moving ball check mechanism for one-direction flow applications and reverse-flow restriction.
- Body material: Polypropylene.
- Valve size: 1 in. nominal size with 1 in. socket connections on side 1 and side 2.
- Valve body style: Inline, 2-way configuration.
- For media: Corrosive chemicals.
- Flow capacity: Cv 11.
- Maximum operating pressure: 235 psi.
- Operating temperature range: 20 degrees F to 70 degrees F.
- Seal material: FKM
- seat material: EPDM.
- Mounting orientation: Horizontal, vertical.
- Overall height: 5 7/8 in.
- Standards: ASTM D1784, ASTM D4101.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 9.00
- Package Height: 5.00
- Package Weight: 0.70
