Check Valve, True Union, Ball, 6", PVC/EPDM, Flanged MPN:TC1600FE
Free Shipping
In Stock
The Hayward True Union Ball Check Valve is a reliable and efficient solution for various applications. Designed for inline use, this valve features a true union design for easy installation and maintenance. Made from durable PVC and EPDM materials, it withstands temperatures up to 140°F and pressures up to 150 psi. Suitable for use in water systems, it allows for 275 gpm flow and is ideal for residential and commercial plumbing, irrigation systems, and water treatment plants. Its compact size and flanged connection make it easy to integrate into existing systems, providing a seamless and leak-free operation.
Top product features:
- True Union design allows for easy disconnection and reconnection of the valve without disturbing the surrounding piping.
- The valve features a single flow design for efficient fluid flow.
- The valve is equipped with an EPDM seal for reliable and long-lasting sealing performance.
Top product applications:
- Water treatment systems
- Swimming pools
- Industrial piping systems
HAYWARD FLOW CONTROL TC1600FE is a 6 in. inline true union ball check valve for process piping systems handling water. It features a PVC body, a PVC ball check mechanism, and EPDM seal and seat materials for one-way flow applications with a ball check mechanism intended to limit reverse flow. The valve has flanged ends and a full-flow design for use in ANSI Class 150 piping systems with a 275 gpm flow rating and 3 psi cracking pressure.
Key Features:
- Inline true union ball check valve design
- 6 in. nominal valve and connection size
- PVC body with PVC ball check mechanism
- EPDM seal and seat materials
- Flange x Flange connections, ANSI Class 150
- Flow rating: 275 gpm
- Cv: 340
- Cracking pressure: 3 psi
- Pressure rating: 150 psi at 70 degrees F
- Operating temperature range: 34 degrees F to 140 degrees F
- Mounting positions: horizontal, vertical, and vertical flow up
- Certifications and standards: NSF 61, ASTM D1784
- Overall dimensions: 19.19 in. L x 11 in. H x 11 in. W
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.20
- Package Width: 14.80
- Package Height: 20.90
- Package Weight: 34.92
