Ball Check Valve, TC Series, 2 1/2 in, Flange x Flange, Inline, CPVC Body MPN:TC2250FE
Free Shipping
In Stock
The Hayward Check Valve is a reliable and efficient solution for your pool or spa system. This US-made valve ensures one-way flow, preventing backwash and maintaining water pressure. Its compact design and lightweight construction make it easy to install and transport. Perfect for pool owners, contractors, and service professionals, the Hayward Check Valve is ideal for new installations or replacements. Its durable construction and long lifespan ensure years of trouble-free operation, while its affordability makes it an attractive option for budget-conscious buyers. Suitable for residential and commercial applications, this valve is a must-have for any pool or spa system.
Top product features:
- It allows fluid to flow in one direction while preventing backflow.
- It is designed for use in high-pressure applications.
- It has a compact design that minimizes space requirements.
Top product applications:
- Pools and hot tubs
- Industrial water treatment systems
- Commercial plumbing systems
The HAYWARD FLOW CONTROL TC2250FE is an inline 2-way ball check valve with a CPVC body for one-way flow control in liquid handling and process piping systems. It uses a free-moving ball check mechanism to permit flow in one direction and close against reverse flow. For media: corrosive chemicals. It has 2 1/2 in flange connections on both sides, a 1.5 psi cracking pressure, and a mounting orientation of horizontal or vertical.
Key Features:
- Ball check mechanism: Uses a ball to permit flow in one direction and close against reverse flow.
- Body material: CPVC.
- Connection size: 2 1/2 in on side 1 and side 2.
- Connection type: Flange on side 1 and side 2.
- Valve body style: Inline, 2-way design.
- Flow coefficient (Cv): 170.
- Maximum operating pressure: 150 psi.
- Cracking pressure: 1.5 psi.
- Operating temperature range: 34 degrees F to 140 degrees F.
- Seal material: EPDM.
- Seat material: EPDM.
- For media: Corrosive chemicals.
- Mounting orientation: Horizontal or vertical.
- Certification: NSF 61.
- Standards: ANSI 372, ANSI 61, ASTM D1784, ASTM D4101.
- Overall height: 11 1/4 in.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 10.00
- Package Width: 10.00
- Package Height: 20.00
- Package Weight: 14.25
