Y-Check Valve, Spring-Loaded, 3", PVC/EPDM, Threaded, Adjustable 2-15 psi MPN:SLC10300TE
Free Shipping
In Stock
The Hayward Y-Check Valve is a reliable and adjustable solution for regulating water flow in various applications. This spring-loaded check valve features a threaded connection and is designed for use in 3-inch PVC/EPDM systems. With a cracking pressure range of 2-15 psi, it provides precise control over water flow, making it ideal for use in irrigation systems, pools, and water treatment facilities. The valve's durable construction and stainless steel spring ensure long-lasting performance, even in extreme temperatures, making it a valuable addition to any system requiring precise water flow management.
Top product features:
- Spring-loaded design allows for automatic opening and closing of the valve
- Adjustable cracking pressure range of 2-15 psi for customizable flow control
- EPDM seal material provides resistance to corrosion and abrasion in a wide temperature range
Top product applications:
- Pools and hot tubs
- Water treatment systems
- Industrial water circulation systems
HAYWARD FLOW CONTROL model SLC10300TE is a 3 in. spring check valve with a Y-style PVC body, FNPT x FNPT threaded connections, and an EPDM seal. This spring-loaded valve is specified for general purpose water service and one-way flow control in horizontal or vertical installations. It features a piston check mechanism with an adjustable spring range of 2 to 15 psi and a cracking pressure of 2.0 psi.
Key Features:
- 3 in. nominal valve size with 3 in. female NPT connections on both ends
- PVC body and check mechanism with EPDM seal
- Seat material: PVC and EPDM
- Y-style body with inline spring design and plug/disc configuration
- Media: water
- Application: general purpose
- Flow rating: 150 gpm
- Cv: 110
- Maximum pressure: 150 psi at 70 degrees F
- Temperature range: 40 degrees F to 140 degrees F
- Mounting orientation: horizontal or vertical
- Spring material: stainless steel
- Standard: ASTM D1784
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.80
- Package Width: 12.40
- Package Height: 7.40
- Package Weight: 10.40
