Ball Check Valve, TC Series, 2 in, Inline, Flange Connection, PVC Body MPN:TC10200FE
Free Shipping
In Stock
The Hayward Check Valve is a reliable and efficient solution for various applications, including pool and spa systems. Its durable design ensures smooth water flow and prevents backflow, protecting equipment and maintaining system performance. Suitable for use in a wide range of environments, this valve is ideal for residential and commercial pools, as well as in industrial settings where consistent water flow is crucial. Its compact size and easy installation make it a convenient choice for new installations or upgrades, providing a hassle-free solution for maintaining optimal system operation.
Top product features:
- Ships in 1 day
- Has a lead time of 1 day
- Is a drop-ship item
Top product applications:
- Pool circulation systems
- Hydrotherapy equipment
- Well pumps
HAYWARD FLOW CONTROL TC10200FE is a 2 in. inline ball check valve with flanged connections on both ends. It uses a free-moving ball check mechanism to allow forward flow and restrict reverse flow. This valve is for use in liquid handling systems and process lines handling compatible corrosive chemical media. It is specified with PVC body, EPDM seal, and EPDM seat materials
- verify compatibility with the intended media. The valve can be mounted in horizontal or vertical orientations.
Key Features:
- Ball check mechanism: Uses a ball to open with forward flow and close when reverse flow is present.
- Valve style: Inline 2-way check valve.
- Body material: PVC.
- Seal and seat material: EPDM seal and EPDM seat.
- Connection size: 2 in. on side 1 and 2 in. on side 2.
- Connection type: Flange on both sides.
- Flow capacity: Cv 130.
- Cracking pressure: 1.5 psi.
- Maximum operating pressure: 235 psi.
- Operating temperature range: 34°F to 140°F.
- Mounting orientation: Horizontal or vertical.
- Media: Compatible corrosive chemical media.
- Overall height: 8 9/16 in.
- NSF certification: NSF 61.
- Standards: ANSI 372, ANSI 61, ASTM D1784, ASTM D4101.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.00
- Package Width: 7.50
- Package Height: 6.00
- Package Weight: 6.05
