Y-Check Valve, Spring-Loaded, 3", PVC/FPM, Threaded, Adjustable 2-15 psi MPN:SLC10300T
Free Shipping
In Stock
The Hayward Y-Check Valve is a reliable and adjustable check valve designed for a wide range of applications. Suitable for use in both horizontal and vertical orientations, this valve features a spring-loaded mechanism that can be adjusted to crack at pressures between 2-15 psi. Constructed with durable PVC and stainless steel components, the valve can withstand temperatures up to 140°F and pressures up to 150 psi. Ideal for use in water treatment systems, irrigation, and industrial processes, the Y-Check Valve provides efficient flow rates of up to 150 gpm and is backed by a lead time of just 5 days.
Top product features:
- Spring-loaded mechanism for easy operation
- Adjustable cracking pressure range of 2-15 psi
- Stainless steel spring for durability and resistance to corrosion
Top product applications:
- Water Treatment Systems
- Pool and Spa Systems
- Industrial Process Control
HAYWARD FLOW CONTROL SLC10300T is a 3 in spring-loaded Y-check valve for one-way flow control in general-purpose water service. This PVC valve uses an inline spring and piston check mechanism to open with forward flow, closing when flow stops or reverses. It features female NPT threaded connections on both ends and can be mounted horizontally or vertically.
Key Features:
- 3 in spring-loaded check valve with Y-style body
- 3 in FNPT x FNPT threaded connections
- PVC body, PVC check mechanism, and PVC seat
- Seal materials: FKM/Viton and carbon-filled TFE
- Cracking pressure: 2.0 psi
- Adjustable pressure range: 2 to 15 psi
- Flow rating: 150 gpm
- Cv: 110
- Maximum pressure: 150 psi at 70 degrees F
- Operating temperature range: 40 to 140 degrees F
- Stainless steel spring
- Horizontal or vertical mounting
- ASTM D1784
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.90
- Package Width: 12.30
- Package Height: 7.10
- Package Weight: 10.20
