Check Valve, True Union, Ball, 6", PVC/FPM, Flanged MPN:TC1600F
Free Shipping
In Stock
The Hayward True Union Check Valve is a reliable and efficient solution for various applications, including water treatment, irrigation, and industrial processes. With a PVC/FPM construction and flanged connections, this valve provides a durable and leak-free operation. Its true union design allows for easy installation and removal, reducing downtime and increasing productivity. The valve's single flow design and 3 psi cracking pressure ensure smooth flow control and prevent backflow. Suitable for temperatures up to 140°F and pressures up to 150 psi, this check valve is ideal for use in various industries where precise control and reliability are crucial.
Top product features:
- True union design for easy installation and maintenance
- Flow design is single, allowing for one-way flow control
- Viton seals for reliable and durable sealing performance
Top product applications:
- Pool and spa systems
- Water treatment plants
- Industrial piping systems
HAYWARD FLOW CONTROL TC1600F is a 6 in true union ball check valve for process piping systems. This inline, single-flow valve is configured for one-direction water flow applications and reverse-flow reduction. It features a PVC body, a PVC ball check mechanism, and flanged end connections. The valve is rated for horizontal or vertical mounting, including vertical flow up.
Key Features:
- 6 in nominal valve and pipe size with flange x flange connections
- Inline true union body design with ball check mechanism
- PVC body and PVC check mechanism
- Seal and seat materials: FKM/Viton
- Media: water
- Cracking pressure: 3 psi
- Flow capacity: 275 gpm
- Cv: 340
- Maximum pressure: 150 psi at 70 degrees F
- Operating temperature range: 34 degrees F to 140 degrees F
- ANSI flange class: Class 150
- NSF 61
- Standards: ASTM D1784
- Overall size: 19.19 in L x 11 in H x 11 in W
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.00
- Package Width: 15.10
- Package Height: 20.90
- Package Weight: 34.02
