Coupler Body, (F)NPT, 1/4, Brass MPN:B23AS25F
The Hansen B23AS25F Quick Connect Hose Coupling Socket is a reliable and efficient solution for construction, air tools, and general pneumatics applications. Its push-to-connect locking mechanism provides easy attachment and release of hoses and equipment without the need for tools, saving time and increasing productivity. Made of durable brass with a zinc-plated finish, this fitting forms a seal at the connection interface and is compatible with various standards, including Industrial Interchange, AR0210, and Tru-Flate. Suitable for a wide range of applications, this coupling offers a maximum flow rate of 792 liters per minute and a maximum working pressure of 150 psi.
Top product features:
- Forms a seal at the connection interface under the specified maximum working pressure and temperature range controlled by an integrated poppet valve.
- Includes a push-to-connect locking mechanism that provides push-to-connect engagement for hose/equipment attachment and release without tools.
- Supports a maximum rated flow rate of 792 liters per minute when used within the specified operating conditions.
Top product applications:
- Construction
- Air tools
- General pneumatics applications
The HANSEN - B23AS25F is a quick connect hose coupling designed for construction, air tools, and general pneumatics applications. It features a push-to-connect locking mechanism that provides push-to-connect engagement for hose/equipment attachment and release without tools (per the push-to-connect locking mechanism). Made of brass with a zinc-plated finish, this fitting is intended to form a seal at the connection interface under the specified maximum working pressure and temperature range controlled by an integrated poppet valve. It is compatible with Industrial Interchange, AR0210, and Tru-Flate standards, supporting a maximum rated flow rate of 792 liters per minute (when used within the specified operating conditions) and a maximum rated working pressure: 150 psi at 70°F (per manufacturer specifications). The coupling is designed with a 1/4 inch size and female hose fitting gender.
Key Features:
- - Material: Brass construction with zinc-plated finish
- - Connection type: 1/4" NPT female thread with a 1/4 inch coupling size
- - Includes a poppet valve to control fluid or air flow
- - Coupling locking type: Push-to-connect mechanism
- - Seal material: Nitrile, suitable for temperatures from -40°F to 250°F
- - Overall length: 2.00 inches with a maximum outside diameter of 15/16 inch
- - Compatible with Industrial Interchange, AR0210, Tru-Flate standards
- - Maximum flow rate: maximum rated flow rate: 792 liters per minute (when used within the specified operating conditions)
- - Maximum working pressure: maximum rated working pressure: 150 psi at 70°F (per manufacturer specifications)
- - Coupling component: Socket
- - Barbed fitting: No
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.70
- Package Width: 1.60
- Package Height: 1.60
- Package Weight: 0.25
