Coupler Body, (M)NPT, 1/4, Brass MPN:RD705LSL
The Hansen Coupler Body is a reliable and efficient solution for various applications, including acetylene service. Its locking type sleeve ensures a secure connection, while its brass construction withstands extreme temperatures from -40 to 250°F. With a maximum flow rate of 21 cfm and pressure of 15 psi, this coupler body is ideal for demanding tasks. Its OSHA compliance and nitrile seals guarantee a safe and leak-free operation. Suitable for use in a range of industries, this coupler body is a valuable addition to any toolkit, providing a reliable and efficient connection for hose and pipe systems.
Top product features:
- Locking Type Sleeve for secure hose connection
- Material Brass for durability and resistance to corrosion
- Seals Nitrile for reliable sealing and protection against leaks
Top product applications:
- Acetylene Service
- Hose Connection (F)NPT
- OSHA Compliant
The HANSEN - RD705LSL is a quick coupler body designed for acetylene service and compatible with 700 Series plugs. This quick connect coupler acts as the stationary half of a hose coupling that receives the plug and contains an internal valve for coupling and uncoupling in fluid and gas systems. Is constructed with a brass body and Buna-N seals (brass finish), it has a maximum flow rate rating of 21 scfm and a maximum working pressure rating of 1,000 psi at 70°F. The coupling uses a sleeve-type locking mechanism and features a (F)NPT connection type with a 9/16"-18 connection size and a 1/4" quick connect air coupling body size.
Key Features:
- - Application: Acetylene Service
- - Material and Finish: Brass body with brass finish
- - Seal Material: Buna-N
- - Connection Type: Female NPT (9/16"-18 thread size)
- - Body Size: 1/4" quick connect air coupling
- - Coupling Locking Type: Sleeve
- - Max Flow Rate: 21 scfm
- - Max Working Pressure at 70°F: 1,000 psi
- - Operating Temperature Range: -40°F to 250°F
- - Color Code: Red
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 120 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.21
