Quick Coupler Body, 700 Series, 1/4 in Female NPTF, Brass, Standard Service MPN:RD703

• The HANSEN - RD703 is a quick coupler body

• the stationary half of a quick-connect hose fitting. It receives the plug and contains an internal valve that opens or closes upon plug engagement, supports coupling engagement and disengagement without a separate tool in pneumatic and fluid systems. This model is for use in service applications within the specified technical ratings and is compatible with 700 Series plugs when used with the specified connection sizes and thread types. It uses 1/4" connection size and 1/4" NPTF female thread size.

  Key Features:


  • - Body size: 1/4" quick connect air coupling
  • - Material: Brass construction with a brass finish
  • - Seal material: Buna-N
  • - Connection type: Female NPTF threads, 1/4"-18 thread size
  • - Coupling locking type: Sleeve mechanism
  • - Rated working pressure: 1,500 psi at 70°F
  • - Rated operating temperature range: -40°F to 250°F
  • - Color code: Red for visual identification
