Instrumentation Check Valve, H400 Series, Inline Spring, 1/4 in MNPT x MNPT, 316 Stainless Steel MPN:H-480OP-SS-N-1/4-10PSI
Free Shipping
In Stock
The Instrumentation Check Valve from Ham-Let is a reliable and efficient one-piece check valve designed for a wide range of applications. Ideal for use in critical systems where backflow must be prevented, this valve ensures the flow of fluids in one direction only, preventing potential damage and contamination. Its compact size and lightweight design make it easy to integrate into existing systems, while its durable construction ensures long-lasting performance. Suitable for use in industries such as oil and gas, power generation, and pharmaceuticals, this valve provides a cost-effective solution for maintaining system integrity and preventing costly downtime.
Top product features:
- One Piece Construction
- Ships in 1 day
- Has a Minimum Order Quantity of 1
Top product applications:
- Pressure Regulator Protection
- Gas Flow Control Systems
- Pneumatic System Safety
HAM-LET H-480OP-SS-N-1/4-10PSI is an instrumentation check valve designed for one-way flow control in small-bore process and instrument lines. This inline, 2-way valve uses a poppet check mechanism for directional flow control in systems using compatible chemicals, gas, oil, or water within the specified ratings. It features male 1/4 in. NPT connections on both ends and can be mounted horizontally or vertically.
Key Features:
- 316 stainless steel body, check mechanism, and seat for the valve’s primary wetted components
- Inline spring design with poppet mechanism for one-way flow control
- 1/4 in. MNPT x MNPT connections for threaded installation
- Cracking pressure: 10 psi
- Flow coefficient (Cv): 0.35
- Maximum operating pressure: 3,000 psi
- Operating temperature range: -10°F to 375°F
- Seal material: FKM
- Spring material: 302 stainless steel
- Overall length: 1.61 in.
- hex size: 9/16 in.
- Valve series: H400
- Standards: C.R.N 0C16552.2
Additional Information
- Country of Origin: IL
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.60
- Package Width: 1.30
- Package Height: 1.20
- Package Weight: 0.10
