Blind Flange, 10 in NPS, 316L Stainless Steel, Raised Face, Class 150, 12 Bolt Holes MPN:FLS61RFBL1000

• The GUARDIANMADE - FLS61RFBL1000 is a 10-inch stainless steel blind pipe flange made from 316L stainless steel. It is intended for use as a blind flange to close off the end of a pipe or pressure vessel opening. This flange features a raised face connection surface and is suitable for use with air, natural gas, oil, and potable water systems. It is manufactured in compliance with ASME B16.5 and ASTM A182 standards and is rated for a maximum pressure of 230 psi in accordance with specified standards.

  Key Features:


  • - Nominal Pipe Size: 10 in
  • - Flange Outside Diameter: 16 in
  • - Bolt Circle Diameter: 14 1/4 in
  • - Number of Bolt Holes: 12
  • - Bolt Hole Diameter: 1 in
  • - Flange Thickness: 1 3/16 in
  • - Connection Type: Blind Flange
  • - Pipe Fitting Material: 316L Stainless Steel
  • - Connection Surface: Raised Face
  • - Pressure Class: Class 150
  • - Maximum Operating Pressure: 230 psi
  • - Standards: ASME B16.5
  • ASTM A182
