Check Valve, 7800 Series, Swing, Inline Wafer, Ductile Iron, 6 5/8 in Grooved MPN:2200750111
Check Valve, 7800 Series, Swing, Inline Wafer, Ductile Iron, 6 5/8 in Grooved
GRUVLOK 2200750111 is a 2-way inline wafer check valve for general-purpose flow control in piping systems. It is configured for one-direction flow with a swing check mechanism for reverse-flow control. This valve features a ductile iron body and is rated for use with specified compatible media, including alkaline solutions, selected chemicals, dilute acids, oil-free air, and water.
Key Features:
- Nominal valve size: 6 5/8 in with 6 5/8 in connections on both sides.
- Connection details: grooved side 1 and side 2
- connection type listed as flanged wafer x flanged wafer
- female connection gender on both sides.
- Body and internals: ductile iron body, 304 stainless steel check mechanism, 304 stainless steel seat, EPDM seal.
- Check design: swing mechanism with inline wafer body design and single flow design.
- Ratings: 700 gpm flow rating, 500 psi cracking pressure, and 300 psi maximum operating pressure.
- Temperature range: -40 Degrees F to 230 Degrees F.
- Mounting orientation: horizontal.
- Full flow: yes.
- Overall dimensions: 12.75 in overall length, 8 1/2 in overall height.
- Spring material: 302 stainless steel.
- Standards: cULus Listed, FM.
- Valve series: 7800.
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.20
- Package Width: 12.60
- Package Height: 12.00
- Package Weight: 34.40
Product info last updated on April 11, 2026 4:49am UTC
Category: Pipes, Valves and Fittings
