Check Valve, 7800 Series, Swing, 3 in, Grooved x Grooved, Ductile Iron, Inline Wafer MPN:2200750061
This 7.75 in overall length check valve from Gruvlok is designed for reliable flow control in various industrial applications. Its inline wafer design and ductile iron body ensure durability and resistance to corrosion, while the EPDM seal and 304 stainless steel seat provide a tight seal and long-lasting performance. Suitable for use in horizontal orientations, this valve can handle up to 500 psi cracking pressure and 300 psi water pressure, making it ideal for use in fire protection systems, HVAC, and municipal water supply applications. Its compact size and ease of installation make it a convenient solution for a range of industrial applications.
Top product features:
- Check Valve, Flow Design Single
- Inline Wafer Body Design
- 304 Stainless Steel Seat Material
Top product applications:
- Water Treatment Plants
- Fire Protection Systems
- Industrial Process Control
GRUVLOK 2200750061 is a 3 in check valve with an inline wafer body design for one-direction flow applications in general purpose piping systems. It is configured with a swing check mechanism for one-direction flow applications. Specified media include water, oil-free air, alkaline solutions, chemicals, and dilute acids.
Key Features:
- 3 in nominal valve size with grooved x grooved female connections
- Inline wafer body design with single-flow configuration
- Ductile iron body
- Swing check mechanism with 304 stainless steel check mechanism and 304 stainless steel seat
- EPDM seal material
- Rated flow: 700 gpm
- Cracking pressure: 500 psi
- Maximum operating pressure: 300 psi
- Operating temperature range: -40 degrees F to 230 degrees F
- Mounting orientation: horizontal
- Overall dimensions: 7.75 in L x 4 15/16 in H
- Standards: cULus Listed, FM
- Valve series: 7800
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.20
- Package Width: 7.00
- Package Height: 4.70
- Package Weight: 9.55
