90° Long Radius Elbow, 2-1/2 in Nominal, Grooved, Schedule 10, 304 Stainless Steel MPN:1330007330
The GRUVLOK - 1330007330 is a 304 Stainless Steel 90° Long Radius Elbow designed for use in grooved-end piping systems. Its corrosion-resistant material makes it suitable for a wide range of applications, including chemical processing, food and beverage, and pharmaceutical industries. This elbow changes the direction of flow by 90 degrees, reducing turbulence and increasing system efficiency. Its long radius design also minimizes pressure drop and reduces the risk of pipe damage. With a nominal pipe size of 2-1/2 inches and a schedule of 10, this elbow is ideal for use in high-traffic areas where durability and reliability are paramount.
Top product features:
- 304 Stainless Steel material provides corrosion resistance
- Changes the direction of flow in a piping system by 90 degrees
- Grooved ends allow for secure connections to other grooved piping components
Top product applications:
- 90° Long Radius Elbow can be used in a chemical processing plant to change the direction of a pipe carrying a corrosive substance, taking advantage of the 304 Stainless Steel's corrosion resistance inherent to the material.
- In a water treatment facility, the 90° Long Radius Elbow can be used to redirect a pipe carrying treated water, ensuring a smooth flow and minimizing turbulence, while the 304 Stainless Steel material provides resistance to corrosion from the water.
- The 90° Long Radius Elbow can be installed in a food processing plant to change the direction of a pipe carrying a food product, such as juice or syrup, and the 304 Stainless Steel material ensures that the product does not come into contact with any contaminants or corrosive substances.
The GRUVLOK - 1330007330 is a 304 Stainless Steel pipe fitting designed as a 90 Degrees Long Radius Elbow with grooved ends on both sides. It is intended to change the direction of flow in a piping system by 90 degrees. The elbow fits nominal pipe sizes of 2-1/2 inches with a pipe schedule of 10. For grooved-end piping systems using 2-1/2 in NPS and Schedule 10
- media compatibility should be verified against applicable codes and service conditions. Material: 304 Stainless Steel
- corrosion resistance inherent to the material. Key Features:
- - Material: 304 Stainless Steel
- - Specific Fitting Shape: 90 Degrees Long Radius Elbow
- - Connection Type (Side A and Side B): Grooved
- - Nominal Pipe Size (Side A and Side B): 2-1/2 in
- - Outside Diameter (Side A): 2 7/8 in
- - For Pipe Schedule: 10
- - Includes Seal: No
- - Includes Pre-Applied Thread Sealant: No
Additional Information
- Country of Origin: TW
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.00
