Check Valve, 7800 Series, Swing, Inline Wafer, Grooved x Grooved, 2 1/2 in, Ductile Iron MPN:2200750046
The Gruvlok Check Valve is a reliable and efficient solution for managing fluid flow in various applications. Designed for inline wafer installation, this valve features a ductile iron body and a 304 stainless steel seat, ensuring durability and resistance to corrosion. With a maximum temperature range of 230°F and a minimum temperature range of -40°F, it can handle a wide range of operating conditions. Suitable for use in water supply systems, irrigation, and fire protection, this check valve provides full flow capabilities and is ideal for applications requiring high water pressure, such as municipal water treatment and industrial processes.
Top product features:
- Flow Design Single
- Inline Wafer Body Design
- 304 Stainless Steel Seat Material
Top product applications:
- Water Supply Systems
- Fire Protection Systems
- Industrial Process Control
The GRUVLOK 2200750046 is a 2 1/2 in check valve with an inline wafer body and swing check mechanism. It is configured for one-direction flow and closure in response to reverse-flow conditions. It is intended for general-purpose service with water, oil-free air, alkaline media, compatible chemicals, and dilute acids. The ductile iron body, EPDM seal, and stainless steel internal components support installation in piping and process systems for backflow-control applications
- listed full-flow specification: Yes.
Key Features:
- Nominal valve size: 2 1/2 in
- Connection type: Grooved x Grooved
- Side 1 connection size: 2 1/2 in
- Side 2 connection size: 2 1/2 in
- Body style: Inline wafer with swing check mechanism
- Body material: Ductile iron
- Check mechanism material: 304 stainless steel
- Seat material: 304 stainless steel
- Spring material: 302 stainless steel
- Seal material: EPDM
- Flow design: Single
- Listed full-flow specification: Yes
- Flow rate: 700 gpm
- Maximum operating pressure: 300 psi
- Cracking pressure: 500 psi
- Operating temperature range: -40 Degrees F to 230 Degrees F
- Mounting orientation: Horizontal
- Overall dimensions: 7.25 in L x 4 1/2 in H
- Standards: cULus Listed, FM
- Valve series: 7800
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.25
- Package Width: 4.50
- Package Height: 4.25
- Package Weight: 10.50
