304 Stainless Steel 90 Street Elbow, 1/2 in x 1/2 in Fitting Pipe Size, Male NPT x Female NPT MPN:40SE113N012
The ZORO SELECT 40SE113N012 is a versatile 304 stainless steel street elbow pipe fitting designed to redirect flow in piping systems. With its male NPT and female NPT ends, this fitting allows for direct connection between pipes and other fittings without the need for short nipples. Suitable for use with air, natural gas, non-potable water, oil, potable water, and steam, this fitting meets Class 150 pressure ratings and is ideal for general service applications up to 300 psi and steam applications up to 150 psi. Its durable construction and reliable performance make it a valuable addition to any piping system.
Top product features:
- 304 Stainless Steel construction
- Meets Class 150 pressure ratings with a maximum operating pressure of 300 psi for general applications and 150 psi for steam
- NPT threading size 14 on both ends for direct connection between a pipe and another fitting without requiring a short nipple
Top product applications:
- air
- natural gas
- potable water
The ZORO SELECT - 40SE113N012 is a 304 stainless steel street elbow pipe fitting designed to change the direction of flow in piping systems. This fitting features one male (MNPT) end and one female (FNPT) end, allowing direct connection between a pipe and another fitting without requiring a short nipple. Compatible with air, natural gas, non-potable water, oil, potable water, and steam within the specified pressure ratings (up to 300 psi general service
- up to 150 psi steam). The fitting meets Class 150 pressure ratings and has a maximum operating pressure of 300 psi for general applications and 150 psi for steam. It comes in a 1/2 inch nominal pipe size with a pipe schedule of 40, and its threading follows ANSI/ASME B1.20.1 standards.
Key Features:
- - Material: 304 Stainless Steel, conforming to ASTM-A-351
- - Configuration: Street Elbow with male (Side A) and female (Side B) threaded ends
- - Connection type: MNPT x FNPT with NPT threading size 14 on both ends
- - Nominal Pipe Size: 1/2 inch for both ends, Outside Diameter: 1/2 inch
- - Pressure Rating: Class 150 with Maximum Operating Pressure of 300 psi and Maximum Steam Pressure of 150 psi
- - Applications: Compatible with air, natural gas, non-potable water, oil, potable water, and steam systems
- - Standards: Meets ASTM-A-351, ANSI/ASME B1.20.1, and MSS-SP-114 Class 150 pressure ratings
- - Color: Silver
- - Does not include pre-applied thread sealant or sealing components
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.20
- Package Width: 1.50
- Package Height: 1.30
- Package Weight: 0.25
