1/4" FNPT Stainless Steel Piston Spring Check Valve MPN:CHK SST 415-4F4F-F
Free Shipping
In Stock
This 1/4in FNPT Stainless Steel Piston Spring Check Valve from GoVets Select is a reliable and efficient solution for various industrial and commercial applications. Its inline piston design allows for smooth and unobstructed flow, while its stainless steel construction ensures durability and resistance to corrosion. The valve's cracking pressure of 1 psi and maximum water pressure of 500 psi make it suitable for a range of applications, including water treatment, HVAC, and hydronic heating systems. Its compact size and horizontal and vertical mounting options make it ideal for use in tight spaces, providing a reliable and efficient flow control solution.
Top product features:
- Stainless Steel construction for corrosion resistance
- Piston design allows for inline installation
- Viton seal material for reliable sealing in a wide temperature range
Top product applications:
- Automotive cooling systems
- Water treatment systems
- Industrial process control systems
GoVets Select Series 415 piston spring check valve with an inline, single-flow design and 1/4 in FNPT x FNPT connections. It uses a stainless steel spring-loaded piston for single-direction flow applications. Intended for general-purpose service with compatible air and fluid applications, this valve is intended for use in piping systems requiring backflow restriction.
Key Features:
- Valve type: Piston spring check valve with inline piston design
- Body material: Stainless steel
- Check mechanism material: Stainless steel
- Connection size: 1/4 in on both sides
- Connection type: FNPT x FNPT
- Connection gender: Female x Female
- Cracking pressure: 1 psi
- Flow design: Single
- full flow: Yes
- Pressure rating: 500 psi maximum operating and water pressure
- Temperature range: -20 degrees F to 180 degrees F
- Seal material: Viton/FKM with TFE, carbon-filled seal
- Seat material: Stainless steel
- Mounting orientation: Horizontal or vertical
- Cv: 1.2
- Hex size: 11/16 in
- Overall length: 1.8 in
- Standards: UL, UR
Additional Information
- Country of Origin: KR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 2.50
- Package Height: 0.80
- Package Weight: 0.55
