2" FNPT 304 SS Union MPN:400U111N020

The ZORO SELECT - 400U111N020 is a stainless steel pipe union designed to join two 2-inch pipe ends with female National Pipe Tapered Thread (FNPT) connections on both sides. Constructed from 304 stainless steel, this union allows for connection or disconnection without rotating connected pipes, facilitating maintenance or replacement. It is rated for a maximum operating pressure of 300 psi and a maximum steam pressure of 150 psi, conforming to Class 150 pressure rating and standards including ASTM-A-351, ASME B1.20.1 threading, and MSS-SP-114. Media compatibility: air, natural gas, non-potable water, oil, potable water, and steam, featuring a gasketed seat and a Class 150 pressure rating.

Key Features:

• - Material: 304 stainless steel with corrosion resistance.
• - Connection Type: Female NPT threaded ends on both Side A and Side B.
• - Nominal Pipe Size: 2 inches on both ends.
• - Pipe Thread Size: 11 threads per inch on both sides.
• - Overall Length: 2.71 inches (69 mm).
• - Pressure Rating: Class 150 with a maximum operating pressure of 300 psi and maximum steam pressure of 150 psi.
• - Hex Size: 89 mm across flats for wrenching.
• - Includes three-piece union design (body, nut, and mating seat/gasket) for maintenance without rotating connected pipes.
• - Meets ASTM-A-351 material standards, ANSI/ASME B1.20.1 threading standards, and MSS-SP-114 Class 150 pressure requirements.
• - Compliance: Low lead compliant for potable water systems.
