3/8" Barb Gray PVC Ball Cone Spring Check Valve MPN:PVC CHK 426-6B6B-B
Free Shipping
In Stock
The GoVets Select 3/8in Barb Gray PVC Ball Cone Spring Check Valve is a reliable and efficient solution for various applications. Suitable for use in horizontal or vertical orientations, this valve features a single flow design and inline ball cone mechanism for smooth operation. With a cracking pressure of 1 psi and a maximum water pressure of 125 psi, it can handle a wide range of fluid pressures. The valve's PVC body and Buna-N seal ensure durability and resistance to corrosion, making it ideal for use in water treatment, irrigation, and other industrial applications where reliability is crucial.
Top product features:
- This check valve is designed for inline use with a ball cone mechanism.
- It features a PVC body material for durability and resistance to corrosion.
- The valve has a stainless steel spring for reliable operation and long lifespan.
Top product applications:
- Water Supply Systems
- Steam Power Plants
- Plumbing Systems
Zoro Select 426 series ball cone spring check valve with an inline PVC body and 3/8 in barb x barb connections. This valve uses a spring-loaded ball mechanism and is configured for one-way flow and reverse-flow restriction in liquid handling applications compatible with the listed materials and operating ranges. Its full-flow design, 1 psi cracking pressure, and horizontal or vertical mounting options mount horizontally or vertically in inline installations.
Key Features:
- Valve type: Ball cone spring check valve with inline body design
- Body material: PVC
- Check mechanism: Ball with stainless steel mechanism material
- Connection size: 3/8 in x 3/8 in
- Connection type: Barb x Barb
- Cracking pressure: 1 psi
- Flow design: Single, full flow
- Seal material: Buna-N
- Seat material: PVC
- Spring material: Hastelloy
- Maximum operating pressure: 125 psi
- Operating temperature range: -20 degrees F to 140 degrees F
- Mounting orientation: Horizontal or vertical
- Standards: NSF 42
- Overall dimensions: 3.53 in L x 1 in H x 1 in W
Additional Information
- Country of Origin: DE
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.00
- Package Width: 5.00
- Package Height: 1.00
- Package Weight: 0.30
