6 in 316/316L Stainless Steel Blind Flange, Class 150, Raised Face, ASME B16.5 MPN:4381001890
This 6-inch 316/316L stainless steel blind flange is designed to close off pipe ends, valves, or pressure vessel openings in piping systems. Made from corrosion-resistant 316/316L stainless steel, it provides durable pressure-tight joints when installed correctly. Conforming to ASME B16.5 standards, this Class 150 flange features a raised face connection surface and is suitable for use in various industries where high-pressure and corrosion-resistant connections are required. Its applications include oil and gas, chemical processing, and pharmaceutical industries, among others. The flange's compact design and easy installation make it a reliable solution for pipeline termination and pressure vessel connections.
Top product features:
- Corrosion resistance and durability for pressure-tight joints when installed correctly.
- Raised face connection surface for gasket seating.
- Solid and flat design for terminating pipeline ends under appropriate installation conditions.
Top product applications:
- Pipe end closure
- Terminating pipeline ends under appropriate installation conditions
- Closing off pipe ends, valves, or pressure vessel openings
The ZORO SELECT - 4381001890 is a stainless steel pipe flange designed as a blind flange to close off pipe ends, valves, or pressure vessel openings. It is made from 316/316L stainless steel, providing corrosion resistance and durability for pressure-tight joints when installed correctly. The flange features a raised face connection surface and conforms to the ASME standards for dimensions, materials, and pressure ratings. This flange is rated Class 150 with a nominal pipe size of 6 inches, intended for use within the specified piping systems.
Key Features:
- - Material: 316/316L Stainless Steel.
- - Flange Type: Blind Flange, solid and flat for terminating pipeline ends under appropriate installation conditions.
- - Pressure Class: Class 150.
- - Nominal Pipe Size: 6 inches.
- - Connection Surface: Raised Face for gasket seating.
- - Number of Bolt Holes: 8.
- - Bolt Hole Diameter: 7/8 inch.
- - Bolt Circle Diameter: 9 1/2 inches center-to-center across bolt holes.
- - Flange Outside Diameter: 11 inches.
- - Flange Thickness: 1 inch.
- - Conforms to the ASME standards for dimensions, materials, and pressure ratings.
Additional Information
- Country of Origin: VN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.00
- Package Width: 11.00
- Package Height: 1.00
- Package Weight: 26.64
