Flange, Aluminum, Butt Weld, 7 in MPN:BULK-PF-464
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G300424510
Flange, Aluminum, Butt Weld, 7 in
This aluminum flange is designed for high-pressure applications in the oil and gas industry. Its 7-inch outside diameter and 2.5-inch nominal pipe size make it suitable for Schedule 40 pipes. The flange features a butt weld design with a 7/8-inch thickness and 4 bolt holes, providing a secure connection. The aluminum alloy 6063 ensures durability and resistance to corrosion. With a maximum operating pressure of 125 psi at 72°F and a maximum steam pressure of 185 psi, this flange is ideal for applications in power plants, refineries, and chemical processing facilities. It is also suitable for use in temperatures ranging from 0°F to 270°F.
Top product features:
- Butt weld design allows for secure and leak-free connections to pipe
- Flat flange design enables easy access and inspection of the weld area
- Four bolt holes with 5.5 in bolt circle diameter provide secure fastening options
Top product applications:
- Pipe Fittings for Water Supply Systems
- High-Pressure Steam Distribution Systems
- Industrial Process Piping Applications
Flange, Flat, 2 1/2 in Nominal Pipe Size, Flanged x Weld Neck, 7 in Flange Outside Diameter, 7/8 in Flange Thickness, 7 in Overall Length, Aluminum, Not Applicable, 6063, Class Class 125, For Pipe Schedule Schedule 40, 125 psi @ 72 Degrees F Maximum Operating Pressure, 185 psi Max. Steam Pressure, 0 Degrees to 270 Degrees F, Number of Bolt Holes 4, 5 1/2 in Bolt Circle Diameter, 3/4 in Bolt Hole Diameter
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.27
- Package Width: 2.22
- Package Height: 3.27
- Package Weight: 1.25
Product info last updated on February 23, 2026 11:03am UTC
Category: Pipes, Valves and Fittings
