1/2" MNPT Brass Piston Spring Check Valve MPN:CHK BRS 810-8M8M-F
Free Shipping
In Stock
This 1/2in MNPT Brass Piston Spring Check Valve is a reliable and efficient solution for various applications, including plumbing, HVAC, and industrial systems. Its single flow design and inline piston mechanism ensure smooth operation and minimize pressure drops. The valve's brass body and stainless steel spring provide durability and resistance to corrosion, while the Viton seal ensures a tight seal up to 180°F. Suitable for horizontal or vertical mounting, this valve is ideal for applications where a high-pressure drop is not acceptable, such as in water supply lines or steam systems. It can withstand up to 500 psi water pressure.
Top product features:
- Piston design allows for inline installation
- Single flow design enables full flow through the valve
- Viton seal material provides reliable sealing up to 180°F
Top product applications:
- Water Pressure Control Systems
- Steam Trapping Systems
- Hydraulic Systems
This 1/2 in. piston spring check valve is a general-purpose inline valve configured for one-direction flow applications with spring-assisted closure when flow slows or reverses. It features a brass body with 1/2 in. MNPT x MNPT connections and is specified for use with air and fluids. The spring-loaded piston design is intended for backflow-control applications
- mounting orientation: horizontal or vertical. Additional specifications include a 1 psi cracking pressure and full-flow construction.
Key Features:
- Valve type: Piston spring check valve with inline piston mechanism
- Body material: Brass
- Connection type: 1/2 in. MNPT x MNPT, male on both ends
- Media: Air, fluids
- Cracking pressure: 1 psi
- Maximum pressure: 500 psi
- Temperature range: -20 degrees F to 180 degrees F
- Seal material: Viton/FKM
- Seat material: Brass
- Spring material: Stainless steel
- Flow design: Single
- full flow: Yes
- Mounting orientation: Horizontal, vertical
- Cv: 2.2
- Overall length: 1.88 in.
- Hex size: 7/8 in.
Additional Information
- Country of Origin: CA
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 4.00
- Package Height: 1.10
- Package Weight: 0.89
