1" MNPT x FNPT 304 SS Street 90 Degree Elbow MPN:2UA71
Free Shipping
In Stock
The ZORO SELECT 2UA71 is a versatile 90 Degree Street Elbow designed to connect two pipes at a right angle, ideal for various industrial and commercial applications. Constructed from durable 304 stainless steel, this fitting excels in high-pressure environments, withstanding up to 3000 psi at 100°F and 2500 psi at 350°F. Compatible with 1-inch MNPT x FNPT threaded connections, it's perfect for plumbing, HVAC, and piping systems. Its compact design and corrosion-resistant material ensure long-lasting performance, making it a reliable choice for use in food processing, chemical plants, and other industries where sanitation and safety are paramount.
Top product features:
- 304 Stainless Steel construction for durability and resistance to corrosion
- Connects two pipes at a right angle for efficient pipe routing and space-saving installation
- Rated for a maximum working pressure of 3000 psi at 100°F for reliable and safe operation
Top product applications:
- Industrial Pipe Fittings for High-Pressure Systems
- Plumbing and HVAC Systems for Residential and Commercial Buildings
- Manufacturing and Processing Lines for Food, Beverage, and Chemical Industries
The ZORO SELECT 2UA71 is a stainless steel pipe fitting designed as a 90 Degree Street Elbow. It connects two pipes at a right angle, forming a 304 stainless steel material rated for a maximum working pressure of 3000 psi at 100°F, compatible with 1-inch MNPT x FNPT threaded connections. The fitting has a male connection on Side A with a 1-inch nominal size and 1-inch NPT threaded ends, and a female connection on Side B, also 1-inch in size with 1-inch NPT threads. It conforms to ASTM A182 standards and ASME B16.11 specifications. Dimensions and thread standards conform to ASTM A182 and ASME B16.11 standards.
Key Features:
- - Material: 304 Stainless Steel
- - Pressure Rating: Class 3000
- Max pressure 3000 psi@100°F
- Max steam pressure 2500 psi@350°F
- - Connection Type: MNPT x FNPT with threaded ends
- - Gender: Side A Male
- Side B Female
- - Pipe Size: Both sides 1 inch
- - Shape: 90 Degree Street Elbow for right-angle pipe turns
- - Standards: ASTM A182
- ASME B16.11
Additional Information
- Country of Origin: TW
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.80
- Package Width: 2.80
- Package Height: 2.40
- Package Weight: 2.33
