3/4 in FNPT 304 Stainless Steel 90° Elbow, Class 3000, ASTM A182, ANSI B16.11 MPN:2UA58
Free Shipping
In Stock
This 3/4 in FNPT 304 Stainless Steel 90° Elbow is a versatile piping solution for a variety of applications, including industrial, commercial, and residential projects. Its 90-degree design allows for efficient change in flow direction, reducing pipe congestion and increasing system performance. Constructed from corrosion-resistant 304 stainless steel, this fitting ensures durability and longevity in high-pressure environments. Suitable for use with steam, water, and other fluids, this elbow is perfect for HVAC, plumbing, and process piping installations, as well as in chemical processing, power generation, and oil and gas industries.
Top product features:
- Fitting shape: 90 Degree Elbow for a right-angle change in piping direction.
- Material: 304 Stainless Steel for corrosion resistance and strength.
- Connection type: Female NPT threaded ends on both sides.
Top product applications:
- Pressure vessel connections
- Industrial pipe systems
- Steam power plant piping
The ZORO SELECT - 2UA58 is a 90 Degree Elbow stainless steel pipe fitting designed to connect two pipes at a right angle (90°) to change flow direction. It is constructed from 304 stainless steel and features female National Pipe Tapered (FNPT) threaded connections on both ends, sized at 3/4 inch. This fitting is rated for a maximum pressure of 3,000 psi at 100°F and a maximum steam pressure of 2,500 psi at 350°F, as specified in product documentation. The elbow is classified as Class 3000 according to industry standards, and meets ASTM-A-182 material standards as well as ANSI/ASME B1.20.1 thread and ASME B16.11 fitting standards.
Key Features:
- - Fitting shape: 90 Degree Elbow for a right-angle change in piping direction.
- - Material: 304 Stainless Steel for corrosion resistance and strength.
- - Connection type: Female NPT threaded ends on both sides.
- - Nominal pipe size: 3/4 inch for both connection ends.
- - Pressure rating: Class 3000 according to industry standards.
- - Max steam pressure: 2,500 psi @ 350°F.
- - Thread size: 14 threads per inch on both connections.
- - Includes no pre-applied thread sealant or sealing components.
- - Meets ASTM-A-182, ANSI/ASME B1.20.1, and ASME B16.11 standards.
Additional Information
- Country of Origin: TW
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 1.81
- Package Height: 2.40
- Package Weight: 1.52
