1/8" FNPT Stainless Steel Piston Spring Check Valve
This 1/8in FNPT Stainless Steel Piston Spring Check Valve is a reliable and durable solution for various applications, including laboratory, medical, and industrial settings. Its inline piston design allows for efficient flow control, while the stainless steel construction ensures resistance to corrosion and high temperatures. The valve's low cracking pressure of 1 psi makes it suitable for applications where precise control is required. It can withstand up to 500 psi of water pressure and operates effectively within a temperature range of -20°F to 180°F, making it a versatile choice for a wide range of industries and applications.
Top product features:
- 1/8in FNPT Stainless Steel Piston Spring Check Valve has a single flow design with an inline piston mechanism.
- The valve has a cracking pressure of 1 psi.
- The valve is made with a stainless steel body and spring, and a Viton seal.
Top product applications:
- Pump protection in low-pressure systems
- Steam trap protection in small steam systems
- Pressure regulation in laboratory equipment
Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Piston, Body Material - Valves Stainless Steel, Pipe or Tube Size 1/8 in, Connection Type FNPT x FNPT, Cracking Pressure 1 psi, Mounting Orientation Horizontal, Vertical, Seal Material Viton, Max. Temp. - Valves 180 Degrees F, Min. Temp. - Valves -20 Degrees F, Max. Water Pressure - Valves 500 psi, Max. Steam Pressure - Valves Not Rated, Seat Material Stainless Steel, Spring Material Stainless Steel
Additional Information
- Country of Origin: KR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.00
- Package Width: 3.00
- Package Height: 0.70
- Package Weight: 0.37
