2 in 90° Elbow, 316 Stainless Steel, Socket Weld, Class 150, ASTM A351, ANSI B16.5 MPN:609E111SW020

The ZORO SELECT - 609E111SW020 is a 90 Degree Elbow stainless steel pipe fitting designed to connect two pipes at a right angle, creating a 90° change in flow direction. Constructed with 316 stainless steel construction, it is suitable for conveying fluids such as air, natural gas, non-potable water, oil, potable water, and steam. The fitting has a Class 150 pressure rating and conforms to ASTM-A-351 material standards and ANSI B16.5 dimensional requirements, including MSS-SP-51 Class 150LB for general dimensions, pressure, and temperature ratings. It features socket weld connections at both ends and 2-inch nominal pipe size. Key Features:

• - 316 stainless steel construction.
• - Pressure class rating: Class 150.
• - Both ends have 2-inch nominal pipe size and 2.375 inches outside diameter.
• - Socket weld connections at both ends.
• - Compatible with pipe schedule 40.
• - Applications include air, natural gas, non-potable water, oil, potable water, and steam.
• - Does not include pre-applied thread sealant or seals.
• - Meets standards: ASTM-A-351, ANSI B16.5, MSS-SP-51 Class 150LB.
