3/4 in FNPT 304 Stainless Steel Cap, Class 150, Schedule 40 MPN:40RDC111N034
Seal and protect your 3/4 inch pipes with the ZORO SELECT 40RDC111N034 stainless steel pipe cap. Made from durable 304 stainless steel, this cap features a female national pipe thread connection, ensuring a secure and leak-free seal. Perfect for line termination, pressure testing, and future pipeline extensions, this cap is rated for use within Class 150 standards and is suitable for steam applications. With a temperature range of -20°F to 350°F, it's ideal for use in a variety of industries, including construction, manufacturing, and HVAC. Its compact design and easy installation make it a convenient solution for any pipe sealing needs.
Top product features:
- Seals the end of a 3/4 inch pipe to stop flow and protect the interior.
- Made from 304 stainless steel for durability and resistance to corrosion.
- Meets ASTM-A-351 material standards, ANSI B1.20.1 thread standards, and MSS-SP-114 Class 150 pressure ratings for safe and reliable operation.
Top product applications:
- Stop flow and protect the pipe interior, suitable for line termination
- Pressure testing
- Allowing for future pipeline extensions
The ZORO SELECT - 40RDC111N034 is a stainless steel pipe cap designed to close and seal the end of a 3/4 inch pipe. Made from 304 stainless steel, this cap features a FNPT (female national pipe thread) connection with a 14-thread size on Side A. It is intended to stop flow and protect the pipe interior, suitable for line termination, pressure testing, or allowing for future pipeline extensions. The fitting is rated for use within the specified pressure rating of Class 150 standards
- overall length and outside diameter are as specified.
Key Features:
- - Material: 304 Stainless Steel
- - Pipe Size: 3/4 inch nominal
- - Connection Type: FNPT with 14 threads on Side A
- - Rated for use within the specified pressure rating of Class 150 standards
- - Rated for use within the specified pressure rating for steam applications
- - Rated for operation within the specified temperature range of -20°F to 350°F
- - Overall Length: 28 mm
- - Outside Diameter: 3/4 inch
- - No pre-applied thread sealant or included sealing components
- - Meets ASTM-A-351 material standards, ANSI B1.20.1 thread standards, and MSS-SP-114 Class 150 pressure ratings
- - Magnetic: No
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.10
- Package Width: 1.50
- Package Height: 1.50
- Package Weight: 0.25
