1 in 304 Stainless Steel Hex Head Plug, Class 150, MNPT MPN:40HP112N010
Seal off your pipes and fittings with confidence using the ZORO SELECT 1 in 304 Stainless Steel Hex Head Plug. Designed for corrosion resistance and temperature tolerance, this plug is rated for operation within -20 to 350 °F and up to 300 psi. Ideal for applications in chemical processing, oil and gas, and pharmaceutical industries, this plug provides a reliable seal when properly torqued and sealed. Its threaded MNPT connection and 3-inch hex head drive style make it easy to install, while its non-magnetic properties ensure it won't interfere with sensitive equipment. Perfect for new installations or replacements.
Top product features:
- 304 Stainless Steel construction provides corrosion resistance and temperature tolerance
- The plug is rated for operation within -20 to 350 °F and up to 300 psi per MSS-SP-114 Class 150
- The plug seals when properly torqued and sealed per standard installation practices, without the need for pre-applied sealant
Top product applications:
- Pipe repair
- Sealing off a pipe or fitting during maintenance or replacement
- Temporary blockage of a pipe or port
The ZORO SELECT - 40HP112N010 is a stainless steel hex head plug designed to close off the end of a pipe, fitting, or port. 304 Stainless Steel
- corrosion resistance and temperature tolerance are inherent material properties
- rated for operation within -20 to 350 °F and up to 300 psi per MSS-SP-114 Class 150. Threaded MNPT connection
- intended to seal when properly torqued and sealed per standard installation practices (no pre-applied sealant). It is rated for MSS-SP-114 Class 150
- maximum operating pressure 300 psi and temperature range -20 to 350 °F per MSS-SP-114 Class 150. This fitting conforms to ASTM-A-351 material standards, has threads that comply with ANSI B1.20.1, and meets MSS-SP-114 Class 150 pressure ratings.
Key Features:
- - Material: 304 Stainless Steel
- - Fitting Shape: Hex Head Plug
- - Connection Type: Male National Pipe Thread (MNPT)
- - Nominal Pipe Size: 1 inch
- - Pressure Class: Class 150
- - Maximum Operating Pressure: 300 psi
- - Maximum Steam Pressure: 150 psi
- - Temperature Range: -20 Degrees to 350 Degrees F
- - Plug Drive Style: 3 inch Hex Head
- - Overall Length: 34 mm
- - Outside Diameter: 1 inch
- - No pre-applied thread sealant
- apply appropriate thread sealant per standard installation practices.
- - Standards: ASTM-A-351
- ANSI B1.20.1
- MSS-SP-114 Class 150
- - Not Magnetic
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.70
- Package Width: 1.70
- Package Height: 1.30
- Package Weight: 0.20
