1-1/4 in FNPT 304 Stainless Steel Cap, Class 150, 300 psi MPN:40RDC111N114

• This stainless steel pipe cap is designed to close and seal the end of a pipe, facilitating line termination and sealing within specified conditions. It features a Class 150 pressure rating and a connection type of FNPT (female national pipe thread), suitable for threaded installations. Constructed from 304 stainless steel conforming to ASTM-A-351, ANSI B1.20.1, and MSS-SP-114 standards, it can operate within a temperature range of -20°F to 350°F. The cap supports a maximum pressure of 300 psi and a maximum steam pressure of 150 psi, ensuring reliable sealing and line termination in various applications.

  Key Features:

  • - Material: 304 Stainless Steel – corrosion-resistant alloy suitable for various environments.
  • - Material Grade: 304
  • - Pressure Ratings: Max. pressure 300 psi
  • Max. steam pressure 150 psi
  • Rated for maximum pressures of 300 psi and 150 psi for steam.
  • - Connection Type: FNPT (female national pipe thread)
  • - Fitting Class: Class 150
  • - Fitting Schedule: Class 150
  • - Pipe Schedule: Not specified
  • - Nominal Pipe Size: 1 1/4 in
  • - Outside Diameter: 1 1/4 in
  • - Overall Length: 32.7 mm
  • - Fitting Shape: Intended for line termination and sealing within specified conditions
  • - Standards Compliance: ASTM-A-351
  • ANSI B1.20.1
  • MSS-SP-114
  • - Temperature Range: -20°F to 350°F
