3" MNPT x FNPT 304 SS Street Elbow MPN:40SE113N030

• The ZORO SELECT - 40SE113N030 is a 3-inch stainless steel street elbow pipe fitting, street elbow with male and female threaded ends to change flow direction

• no short nipple required. Constructed from 304 stainless steel, this Class 150 fitting is rated for a maximum operating pressure of 300 psi and supports a range of applications including air, natural gas, non-potable water, oil, potable water, and steam. Both ends feature standard NPT threading: a male (street) end and a female (socket) end, enabling compact piping configurations due to street elbow design with threaded ends. Key Features:

  • - Constructed from 304 Stainless Steel alloy.
  • - Pipe size: 3" nominal diameter on both ends.
  • - Connection type: Male NPT (8 threads per inch) on Side A
  • Female NPT (8 threads per inch) on Side B.
  • - Pressure rating: Class 150 with maximum operating pressure of 300 psi.
  • - Rated steam pressure up to 150 psi.
  • - Street elbow configuration with one male and one female threaded end.
  • - Applications include air, natural gas, non-potable water, oil, potable water, and steam systems.
  • - Meets ASTM-A-351 material standards, ANSI/ASME B1.20.1 thread standards, and MSS-SP-114 Class 150 pressure ratings.
  • - Color: Silver.
  • - Does not include pre-applied thread sealant or seals.
