1/4" FNPT Brass Poppet Spring Check Valve MPN:CHK BRS 450-4F4F-B
Free Shipping
In Stock
This 1/4in FNPT Brass Poppet Spring Check Valve from GoVets Select is a reliable and efficient solution for various applications, including water and steam systems. Its single-flow design and inline poppet mechanism ensure smooth operation and minimize pressure drop. The valve's cracking pressure is set at 1 psi, making it suitable for applications requiring precise control. With a maximum temperature range of 180°F and maximum water pressure of 1,200 psi, this valve is perfect for use in industrial settings, such as HVAC systems, water treatment plants, and chemical processing facilities. It also features a durable Buna-N seal and stainless steel spring for long-lasting performance.
Top product features:
- The product has a Poppet mechanism and Inline body design.
- The valve has a Spring-loaded design for automatic shut-off.
- The valve is designed for Full Flow, allowing unobstructed passage of fluid when not in use.
Top product applications:
- Water Supply Systems
- Steam Traps
- High-Pressure Pipe Systems
Zoro Select 450 series poppet spring check valve with an inline brass body and 1/4 in. FNPT x FNPT connections. This valve for water service is specified for water service and has a spring-loaded poppet configuration for one-way flow applications. Its full-flow design, 1 psi cracking pressure, and horizontal or vertical mounting options support use in fluid handling systems requiring one-way flow control.
Key Features:
- Poppet spring check valve with inline body design for one-way flow control
- Brass body, brass seat, stainless steel spring, and Buna-N seal
- 1/4 in. female NPT connections on both ends
- Cracking pressure: 1 psi
- Maximum water pressure: 1200 psi
- Operating temperature range: -20°F to 180°F
- Full-flow design
- Mounting orientation: horizontal or vertical
- Overall length: 1 1/2 in.
- Standards: UL, UR
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 4.50
- Package Height: 0.70
- Package Weight: 0.55
