1/2" MNPT Brass Piston Spring Check Valve MPN:CHK BRS 810-8M8M-B
Free Shipping
In Stock
This 1/2in MNPT Brass Piston Spring Check Valve is a reliable solution for various applications, including water treatment, irrigation, and HVAC systems. Its inline piston design ensures full flow and prevents backflow, while the brass body and Buna-N seal provide excellent corrosion resistance and durability. The valve's cracking pressure is just 1 psi, making it suitable for low-pressure applications. With a maximum temperature rating of 180°F and a maximum water pressure rating of 500 psi, this valve is a versatile choice for a wide range of industries and installations. It's also easy to install and maintain.
Top product features:
- Piston mechanism allows for inline flow control
- Full flow design enables unobstructed fluid passage
- Buna-N seal provides a durable and chemical-resistant seal
Top product applications:
- Water supply systems
- Hydraulic systems
- Steam-free applications requiring a check valve
ZORO SELECT Series 810 check valve is an inline piston spring check valve for use with air and fluid media. It is designed for one-direction flow applications and includes a spring-loaded piston check mechanism. This brass valve features a full-flow design with 1/2 in. MNPT x MNPT connections and can be mounted horizontally or vertically.
Key Features:
- Inline piston spring check valve with brass body, brass check mechanism, and brass seat
- 1/2 in. male NPT connections on both ends (MNPT x MNPT)
- Cracking pressure: 1 psi
- Media: air and fluids
- Maximum pressure: 500 psi
- Temperature range: -20 degrees F to 180 degrees F
- Seal material: Buna-N
- Spring material: stainless steel
- Full-flow design
- Mounting orientation: horizontal or vertical
- Valve series: 810
- Overall length: 1.88 in.
- Overall height/width: 7/8 in.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 3.40
- Package Height: 1.10
- Package Weight: 0.90
