Capacitor-Start Belt Drive Motor, 1/4 HP, 48YZ Frame, 115/208-230V AC Voltage, 1, 725 Nameplate RPM MPN:1AGG1
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1290274
Capacitor-Start Belt Drive Motor, 1/4 HP, 48YZ Frame, 115/208-230V AC Voltage, 1, 725 Nameplate RPM
This 1/4 HP Capacitor-Start Belt Drive Motor is a reliable and efficient solution for a wide range of applications, including ventilation systems, industrial fans, and blowers. With a nameplate RPM of 1,725, it provides consistent performance and is designed for continuous duty cycles in temperatures up to 40°C. The motor's capacitor-start design and 48Y frame ensure optimal power delivery and durability. Suitable for use at 115/208-230V AC voltage, it's a versatile and cost-effective option for various industries, including HVAC, manufacturing, and construction. Its compact design and open drip-proof enclosure make it easy to install and maintain.
Top product features:
- Capacitor-start design for reliable and efficient operation
- Single-phase motor for compatibility with common household electrical systems
- Open drip-proof enclosure for protection against dust and moisture
Top product applications:
- Air Purification System
- HVAC Unit
- Industrial Fan
Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, 6.2/2.8-3.1 A Full Load Amps, 48Y Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.35, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.60
- Package Width: 8.50
- Package Height: 9.50
- Package Weight: 14.80
Product info last updated on February 3, 2026 9:31am UTC
Category: Motors
