Spring Check Valve, Inline, 3/4 in, Sweat x Sweat, Bronze Body MPN:6AJY8
Free Shipping
In Stock
The GoVets Select 3/4in Solder Bronze Spring Check Valve is a reliable and efficient solution for various applications. Suitable for general-purpose use, this valve ensures one-way flow, preventing backflow and contamination. Its high-quality bronze body and 304 stainless steel spring provide excellent durability and corrosion resistance. With a maximum temperature rating of 250°F and a maximum water pressure of 200 psi, this valve is ideal for use in industrial, commercial, and residential settings. Its compact design and easy installation make it a convenient choice for plumbers and engineers.
Top product features:
- 3/4in Solder Bronze Spring Check Valve has a cracking pressure of 3.5 psi
- It features a 304 Stainless Steel spring
- It has a flow rate of 15 gpm
Top product applications:
- General Purpose
- General Purpose
- General Purpose
This 3/4 in. inline spring check valve is designed for general-purpose water service. It uses a spring-loaded internal mechanism to allow flow in one direction and is intended to restrict reverse flow when flow stops or reverses. The bronze body features sweat x sweat connections for use with soldered piping systems. The valve can be mounted horizontally or vertically, with flow up only in vertical installations.
Key Features:
- Valve type: Inline spring check valve
- Application/media: Water
- Size: 3/4 in. nominal valve size with 3/4 in. x 3/4 in. connections
- Connection type: Sweat x sweat
- solder connection
- Body material: Bronze
- Check mechanism and spring material: 304 stainless steel
- Cracking pressure: 3.5 psi
- Flow rating: 15 gpm
- Maximum pressure: 200 psi
- Maximum temperature: 250 degrees F
- Mounting position: Horizontal or vertical
- flow up only in vertical installations
- Standards: ANSI B16.18, MSS SP-80
- Overall length: 3.53 in.
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.60
- Package Width: 1.70
- Package Height: 1.70
- Package Weight: 0.70
