3 in FNPT 304 Stainless Steel Cap, Class 150, Schedule 40 MPN:40RDC111N030
Free Shipping
In Stock
The ZORO SELECT 40RDC111N030 is a reliable and versatile stainless steel pipe cap designed for use in various piping systems. Its threaded FNPT connection allows for easy installation and removal, making it ideal for line termination, pressure testing, and future extensions. Constructed from 304 stainless steel, this cap can withstand temperatures between -20 to 350 degrees Fahrenheit and pressures up to 300 psi, with steam pressure up to 150 psi. Suitable for use in Class 150 pressure-rated piping systems and schedule 40 pipes, this cap is a valuable addition to any industrial or commercial setting.
Top product features:
- It features a threaded FNPT connection, allowing for removable installation.
- The cap is rated for use with Class 150 pressure-rated piping systems and pipe schedule 40.
- Made from 304 stainless steel, it is rated for temperatures between -20 to 350 degrees Fahrenheit.
Top product applications:
- Line termination
- Pressure testing
- Future extensions
The ZORO SELECT - 40RDC111N030 is a stainless steel pipe cap designed to close and seal the end of a 3-inch pipe, stopping flow and protecting the pipe interior. It features a threaded FNPT connection, allowing for removable installation. The cap is rated for use with Class 150 pressure-rated piping systems and pipe schedule 40. Made from 304 stainless steel, it is rated for temperatures between -20 to 350 degrees Fahrenheit, with a maximum allowable pressure of 300 psi and steam pressure up to 150 psi. This cap is suitable for line termination, pressure testing, and future extensions.
Key Features:
- - Material: 304 Stainless Steel
- - Connection Type: Female National Pipe Thread (FNPT)
- - Nominal Pipe Size: 3 inches
- - Rated for use with pressure systems up to 300 psi
- - Rated to withstand steam pressures up to 150 psi
- - Pipe Schedule Compatibility: Schedule 40
- - Temperature Range: -20 to 350 degrees Fahrenheit
- - Overall Length: 47.5 mm
- - Conforms to relevant ASTM, ANSI/ASME, and MSS standards
- - No pre-applied thread sealant or included seal
- - Not magnetic
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.00
- Package Width: 8.00
- Package Height: 8.00
- Package Weight: 12.90
