Reducing Coupling, 316 Stainless Steel, 1/2 in x 1/8 in FNPT, Class 150 MPN:4381036230

• The ZORO SELECT - 4381036230 is a 316 stainless steel reducing coupling designed to connect two pipes of different diameters, transition described with objective specifications: outside diameter 1-3/16", overall length 1-3/4", material 316 stainless steel. It features female National Pipe Taper (NPT) threaded connections on both ends, with nominal pipe sizes of 1/2 inch on Side A and 1/8 inch on Side B. Rated for Class 150

• maximum operating pressure: 300 psi at 150°F.

  Key Features:


  • - Material: 316 stainless steel.
  • - Connection Type: Female NPT threaded ends on both Side A and Side B.
  • - Nominal Pipe Sizes: 1/2" on Side A by 1/8" on Side B.
  • - Pressure Rating: Class 150
  • maximum operating pressure: 300 psi at 150°F.
  • - Compliance: Meets ASTM A-351 for material, ANSI/ASME B1.20.1 for threads, and MSS-SP-114 Class 150 pressure standards.
  • - Dimensions: Outside diameter of 1-3/16" and overall length of 1-3/4".
  • - Does not include pre-applied thread sealant or sealing components.
