1/2 in 304 Stainless Steel Blind Flange, Class 300, Raised Face, 4-Bolt, 3.75 in OD MPN:4381003400
This 1/2 in 304 Stainless Steel Blind Flange is designed to create a sealed termination point in piping systems, ideal for use in high-pressure applications such as chemical processing, oil and gas, and power generation. Constructed from forged 304/304L stainless steel, it offers excellent corrosion resistance and durability. The raised face connection surface and 4-bolt design ensure a secure and leak-free connection. With a maximum operating pressure of 720 psi and a maximum steam pressure of 300 psi, this blind flange is suitable for a wide range of industries and applications, including pharmaceutical, food processing, and water treatment.
Top product features:
- Forged from 304/304L stainless steel for corrosion resistance and durability.
- Raises the face of the flange to ensure a secure and leak-free connection.
- Supports a maximum operating pressure of 720 psi for reliable performance in high-pressure applications.
Top product applications:
- Pipe Fitting and Flange Installation
- Pump and Compressor Mounting
- High Pressure Steam System Termination Point
The ZORO SELECT - 4381003400 is a forged blind flange made of 304/304L stainless steel. It is designed to close off the end of a 1/2-inch nominal pipe size in a piping system by bolting to a mating flange with a gasket, creating a sealed termination point. The blind flange features a raised face connection surface and bolted connection type. It is compatible within the specified pressure ranges and supports a maximum operating pressure of 720 psi and a maximum steam pressure of 300 psi.
Key Features:
- - Material: Forged 304/304L stainless steel
- - Nominal Pipe Size: 1/2 inch
- - Class Rating: Class 300 (pressure class)
- - Maximum Operating Pressure: 720 psi
- - Maximum Steam Pressure: 300 psi
- - Connection Type: Bolted with raised face
- - Number of Bolt Holes: 4 with 5/8 inch diameter
- - Bolt Circle Diameter: 2 5/8 inches
- - Flange Outside Diameter: 3 3/4 inches
- - Flange Thickness: 5/8 inch
- - Overall Length: 9/16 inch
Additional Information
- Country of Origin: KR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.80
- Package Width: 3.80
- Package Height: 0.60
- Package Weight: 1.59
