Reducing Coupling, 2-1/2 x 2 in, FNPT, 304 Stainless Steel, Class 150 MPN:40RC111N212020

• The ZORO SELECT - 40RC111N212020 is a reducing coupling made of 304 stainless steel, designed to join two pipes of different diameters in a piping system. This compact fitting provides a transition between a 2-1/2 inch and a 2 inch nominal pipe size with FNPT female threaded connections on both ends. Maximum operating pressure: 300 psi

• Maximum steam pressure: 150 psi. Intended for use with air, natural gas, non-potable water, oil, potable water, and steam within the specified pressure ratings. The fitting is classified as Class 150, aligning with industry standards for pressure ratings, and conforms to ASTM-A-351 material requirements and ANSI/ASME B1.20.1 threading specifications.

  Key Features:


  • - Material: 304 Stainless Steel
  • - Pipe Sizes: 2-1/2" x 2" nominal pipe size
  • - Connection Type: Female NPT on both ends
  • - Pressure Rating: Class 150
  • Maximum operating pressure: 300 psi
  • - Applications: Air, natural gas, non-potable water, oil, potable water, and steam
  • - Thread Size (Side A & B): 11 TPI
  • - Overall Length: 73.7 mm
  • - Compliance: Low Lead Compliant for potable water systems
  • - Standards: ASTM-A-351, ANSI/ASME B1.20.1, meets MSS-SP-114 Class 150 pressure ratings
  • - Color: Silver
