3" FNPT 304 SS Union MPN:400U111N030
The ZORO SELECT - 400U111N030 is a versatile 3-inch stainless steel pipe union ideal for various industrial and commercial applications. Suitable for use with air, non-potable water, potable water, oil, and steam, this Class 150 fitting allows for easy connection or disconnection without rotating the pipes, reducing maintenance time and effort. Constructed from 304 stainless steel for corrosion resistance, it meets international standards for material, threads, and pressure rating. Perfect for applications in HVAC, plumbing, and industrial systems, this union ensures leak-tight performance and complies with low lead requirements for potable water systems, making it a reliable choice for various industries.
Top product features:
- The product is constructed from 304 stainless steel material for corrosion resistance.
- The product features female NPT connections on both sides with 8 threads per inch, allowing for connection or disconnection without rotating the pipes.
- The product is rated for a maximum operating pressure of 300 psi and maximum steam pressure of 150 psi, making it suitable for various applications.
Top product applications:
- Steam heating systems
- Industrial piping systems for oil and gas
- Potable water distribution systems
The ZORO SELECT - 400U111N030 is a 3-inch stainless steel pipe union designed to join two pipe ends with female NPT threaded connections on both sides. This Class 150 fitting allows connection or disconnection without rotating the pipes
- maintenance actions follow standard threaded connection procedures
- no claim on maintenance speed. Rated for use with air, non-potable water, potable water, oil, and steam within the product's material and pressure specifications
- natural gas compatibility is not specified. Rated for a maximum operating pressure of 300 psi
- leak-tight performance depends on proper installation and use within specified limits. Meets standards: ASTM-A-351 for material, ANSI/ASME B1.20.1 for threads, and MSS-SP-114 for Class 150 pressure rating. Overall length of 83 mm with a hex size of 118.7 mm across flats for wrenching. Does not include pre-applied thread sealant or seals. Complies with low lead requirements for potable water systems.
Key Features:
- - Constructed from 304 stainless steel material for corrosion resistance.
- - Rated for a maximum operating pressure of 300 psi and maximum steam pressure of 150 psi.
- - Features female NPT connections on both Side A and Side B with 8 threads per inch.
- - Meets standards: ASTM-A-351 for material, ANSI/ASME B1.20.1 for threads, and MSS-SP-114 for Class 150 pressure rating.
- - Overall length of 83 mm with a hex size of 118.7 mm across flats for wrenching.
- - Does not include pre-applied thread sealant or seals.
- - Complies with low lead requirements for potable water systems.
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.00
- Package Width: 8.00
- Package Height: 8.00
- Package Weight: 30.60
