Molded Case Circuit Breaker, TEYD Series, 90A, 3 Pole, 277/480V AC, 25kA at 277/480V AC MPN:TEYD3090B
Molded Case Circuit Breaker, TEYD Series, 90A, 3 Pole, 277/480V AC, 25kA at 277/480V AC
The GE TEYD Series 90A 3 Pole Molded Case Circuit Breaker is a reliable and efficient solution for a wide range of applications, including commercial and industrial lighting systems. Designed for use with GE AS Lighting Panels, this circuit breaker provides maximum protection and safety, with a 25kA interrupting rating at 277/480V AC. Its thermal magnetic trip type and instantaneous trip fixed feature ensure quick and accurate response to fault conditions. Ideal for applications requiring high ampacity and reliability, this circuit breaker is a great choice for electrical contractors and facilities managers looking to upgrade their electrical systems.
Top product features:
- Trip Type Thermal Magnetic, which provides a reliable and fast response to overloads and short circuits
- Phase Three, Instantaneous Trip Fixed, which allows for quick and automatic shutdown in the event of a fault
- Terminal Connection Lug, which enables easy and secure connections to the circuit breaker
Top product applications:
- Commercial Lighting Panels
- Industrial Power Distribution Systems
- Electrical Substations
Molded Case Circuit Breaker, 90 A Amps, AC Voltage Rating 277/480V AC, Max. AIR Rating 25kA at 277/480V AC, For Use With GE AS Lighting Panels, Series TEY, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 125A/TEY, Circuit Breaker Mounting Style Bolt On Panelboard, Height 5.2 in, Width 3 in, Depth 3 in, Min. Wire Size 4 AWG, Max. Wire Size 2 AWG
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 30 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.25
- Package Width: 6.00
- Package Height: 5.25
- Package Weight: 2.00
Product info last updated on January 13, 2026 1:36pm UTC
Category: Circuit Protection
