Molded Case Circuit Breaker, TEYL Series, 90A, 3 Pole, 277/480V AC, 65kA at 277/480V AC MPN:TEYL3090B
Molded Case Circuit Breaker, TEYL Series, 90A, 3 Pole, 277/480V AC, 65kA at 277/480V AC
The GE TEYL Series 90A, 3-Pole Molded Case Circuit Breaker is a reliable and efficient solution for electrical distribution systems. Designed for use with GE AS Lighting Panels, this circuit breaker provides high interrupting capacity of 65kA at 277/480V AC, making it ideal for industrial and commercial applications. Its thermal magnetic trip type ensures fast and accurate overload protection, while its bolt-on panelboard mounting style offers easy installation. With a compact design and wide voltage range, this circuit breaker is perfect for use in a variety of settings, including factories, offices, and shopping centers, providing safe and reliable electrical power distribution.
Top product features:
- Three-pole circuit breaker design allows for simultaneous control of three phases of electrical power.
- Thermal magnetic trip type provides instantaneous protection against overcurrent and short circuits.
- Bolt-on panelboard mounting style allows for easy installation on standard panelboards.
Top product applications:
- Lighting Panels
- Industrial Control Panels
- Electrical Distribution Boards
Molded Case Circuit Breaker, 90 A Amps, AC Voltage Rating 277/480V AC, Max. AIR Rating 65kA at 277/480V AC, For Use With GE AS Lighting Panels, Series TEY, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 125A/TEY, Circuit Breaker Mounting Style Bolt On Panelboard, Height 5.2 in, Width 3 in, Depth 3 in, Min. Wire Size 4 AWG, Max. Wire Size 2 AWG
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 30 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.25
- Package Width: 6.00
- Package Height: 5.25
- Package Weight: 2.00
Product info last updated on January 13, 2026 1:35pm UTC
Category: Circuit Protection
