Gast 120R Rocking Piston Compressor MPN:120R689-P101-N800NX
Gast 120R Rocking Piston Compressor
The Gast 120R Rocking Piston Compressor is a reliable and efficient solution for a variety of applications, including laboratory, medical, and industrial use. Its compact design and quiet operation make it ideal for use in sensitive environments, while its high-pressure output and fast recovery time make it suitable for demanding applications. This compressor is perfect for powering tools, equipment, and instruments that require a consistent and reliable air supply. With its fast lead time and flexible ordering options, the Gast 120R is an excellent choice for businesses and individuals looking for a high-quality compressor that meets their specific needs.
Top product features:
- Rocking piston design for efficient compression
- Compressor unit with a compact design
- Ships with a lead time of 1 day
Top product applications:
- Laboratory equipment
- Medical equipment
- Industrial pneumatic systems
The Gast 120R689-P101-N800NX is an oil-free, twin-cylinder piston air compressor with a rocking-piston design. It operates on 200-240V AC single-phase power at 60 Hz at a rated 2 hp output, in a tankless configuration. The oil-free design means the compression chamber runs without lubricant. It provides a free-air flow rate of 12 scfm, a maximum continuous pressure of 145 psi, and a maximum vacuum of 28 in Hg. It has a maximum speed of 1,725 RPM, a full-load current of 9.5 A, and a measured sound level of 75 dBA. The operating temperature range is 32 to 104°F. Construction includes a steel cylinder, and a capacitor-start motor. Air connections are 3/8 in NPT inlet and outlet. Overall dimensions are 15.4 x 10.5 x 12.6 in (L x W x H). Duty cycle: continuous. Rated life expectancy: 20,000 hr.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 21.70
- Package Width: 13.10
- Package Height: 14.50
- Package Weight: 62.50
Product info last updated on February 4, 2026 12:11pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
