Piston Air Compressor, Size 1/4", 1460 RPM MPN:2HAH-19C-M322A
Piston Air Compressor, Size 1/4", 1460 RPM
The Gast Standard 2Hah-19C-M322 Piston Pump is a reliable and efficient oilless piston air compressor designed for a variety of applications. Suitable for use in laboratories, medical facilities, and industrial settings, this pump provides a consistent flow rate of 1.7 cfm at 100 psi, making it ideal for powering pneumatic tools and equipment. With a compact design and low maintenance requirements, this pump is perfect for applications where space is limited and downtime is costly. Its 12V DC power source and single-phase operation make it easy to integrate into existing systems, providing a reliable and efficient solution for a range of pneumatic needs.
Top product features:
- Lubrication Type Oilless
- Piston Air Compressor
- Maximum Continuous Pressure 100 psi
Top product applications:
- Air-powered tools and equipment
- Vacuum systems
- Laboratory and testing equipment
The Gast 2HAH-19C-M322A is an oil-free, single-cylinder piston air compressor with a reciprocating design. It runs on 12V DC power at a rated 0.42 hp output, in a tankless configuration. The oil-free design means the compression chamber runs without lubricant. It provides a free-air flow rate of 1.7 cfm, and a maximum continuous pressure of 100 psi. It has a maximum speed of 1,460 RPM, a full-load current of 35.5 A, and a measured sound level of 75 dBA. The operating temperature range is 41 to 104°F. Construction includes an aluminum cylinder, a brushed DC motor, and stainless steel valves. Enclosure type is clean dust free. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 12.16 x 8.36 x 5.81 in (L x W x H). Duty cycle: continuous. Rated life expectancy: 2,000 hr.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 17.60
- Package Width: 11.70
- Package Height: 12.10
- Package Weight: 19.40
Product info last updated on January 28, 2026 4:48pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
